INQUIRYProduct Feature
1. Double cavity design: Printing area is big cavity. loading area is small cavity that usingthe printing dead time to do the loading and unloading action to increase production
capacity.
2. Printing type: Use to screen printing, non-extruding ink and do not have to waste ink.
3. Printing method: Use to screen printing, can do the cover point on the screen , can do
the selective via hole , does not have to comprehensively printing and change original
process.
Product Specification
Machine Specifications
| Power Supply | AC 220V / 380V, 3-Phase |
| Working Height | 1200 + 30 mm |
| Air Pressure Requirement | 6–8 kg/cm² |
| Table Dimensions | Upper Table: X900 × Y800 mm Lower Table: X900 × Y800 mm |
| Printable Area | Min: X350 × Y250 mm Max: X715 × Y635 mm |
| Frame Size Capacity | Min: W1050 × D1000 mm Max: W1150 × D1100 mm |
| Machine Dimensions | L3450 × W2700 × H2300 mm (excluding vacuum pump and piping) |
